NP-58 Gluing machine
| Product No | NP-58 |
|---|---|
| Model name |
NP-58 Gluing machine |
Machinical explanation
Roll coater of gluing under side for rubber glue
Machinical feature
①Gluing width : 50mm, by using upper presser foot
②Possible to glue to materials with skiving angle easily
Quality of glue : Rubber glue(Recommendable viscosity: 15,000cps)
Gluing side : Under side
Capacity of tank : 1.8L
Specification
| Gluing wide | 50mm |
|---|---|
| Main usage | Gluing machine for rubber (Under side) |
| Machine size | 230 L (mm) x 500 W (mm) x 285 H (mm) |
| Weight | 35 kg |
| Remarks | Remarks : Necessary to arrange a table, stand and general-purpose motor. |
|---|
